EKSTRA 330SX 103'' 2.63M KIRMIZI MAVİ BEYAZ
Net Alış Fiyatınız
1.849,00 USD + KDVNet Alış Fiyatınız
Taksit Seçenekleri
Taksit Seçenekleri
Taksit Seçenekleri
Taksit Seçenekleri
Taksit Seçenekleri
Taksit Seçenekleri
Taksit Seçenekleri
Now, Pilot-RC is proud to announce our next masterpiece.
The Extra 330SX is the latest variation of the Extra family. Each version has different flight characteristics. The ultimate goal is to achieve maximum aerobatic performance on every release. The Extra 330SX resulted in a more precise, floaty, and much more agile plane.
Leading the project design, Ryu Sintuphrom and our factory team pilots thoroughly carried out a long development and test process to get the best performance.
During the process, we tested many design ideas with no compromises; we tested different wing profiles, aileron designs, and wing positions on the fuselage to find the CG sweet spot for all flying styles.
Ultimately, our factory team pilots were very satisfied with the performance of this airframe, leading to the final product.
We proudly and confidently say this airframe achieved the best performance balance ever. In a few words, it’s super precise in high speed/energy but also super stable and predictable at slow speeds.
Combining Pilot-RC’s latest build innovations, this new design provides a superb-quality kit. It includes the NEW 2025 quick-release stabilizer system. This new feature is quick, solid, and convenient, designed to minimize the setup time once in the field.
The Pilot-RC Extra 330SX represents the new era of 120cc 3D Aerobatics.
Specifications:
| Model: | Extra 330SX |
| Wingspan: | 103″ (2.639m) |
| Length: | 102″ (2.60m) with spinner 5″ |
| Wing area: | 1,925″² ( 12,420cm²) |
| Weight: | 27.1lbs (12.3kg) |
FEATURES:
- Hybrid construction from wood and composite materials for specially reinforced fuselage and wings.
- Patented quick assembly system for wings,
- NEW! 2024 quick assembly system for Stabilizer no need tools anymore
- Patented quick assembly system for canopy.
- NEW! Canopy pin more reliable fix it by Screw and New Material hole to stop vibration
- Film covering applied over a Genuine German Oracover (Ultracote) base
- Highly prefabricated, experienced builders can have air ready in under a day
- Pre-installed hinges (glued and pinned)
- Internally mounted cowling – so no visible external screws exposed
- Removable wings and stabs
- Laser engraved motor mounting position
- Easy canister installation due to open construction
- Pull push system for Rudder servo
- Removable landing gear sperate left and right side
Included hardware:
- Complete air frame with all basic accessories (such as carbon fiber main undercarriage, tail-gear assembly and wing-tubes as well as fiberglass control horns and wheel pants)
- “Spare” lower section cowl from transparent plastic – used to mark out correct location to cut the cowl for perfect fitting every time
- Pre-installed hinges and pre-mounted canopy
- Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
- Wheels, axles and wheel pants
- Pre-prepared pushrods with ball links
- Matching carbon spinner, 5″
CRASH KITS AVAILABLE FOR THIS MODEL:
- Landing gear repair package. Includes the wooden parts required to repair the damage often suffered around the landing gear area.
- Front fuselage repair package. Includes the wooden parts required to repair the damage often suffered around the front of the model
- Please note that additional or alternative spare wood outside of the above Packs is not available to order.
Required hardware:
Motor: 100-130cc or equivalent electric
Servos: 5 high torque plus throttle // Uses x2 per aileron, x1 per elevator half and x1 on rudder
Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.
Pilot-Rc recommended hardware:
- Servos: Pilot-Rc PW48AH (48Kg – 0,11s at 8,4v)
- Servo arms: Pilot-Rc 1,6″ Aluminium arms (included with Pilot-Rc servos)
- Wingbags: Pilot-RC wingbags
Extension wire lengths:
Throttle:
35cm
Each aileron:
25+75cm
(to reach receiver direct)
(nearest servo and furthest servo – to reach receiver direct)
Each elevator:
145cm
Rudder:
130cm
CENTER OF GRAVITY:
210mm
Measured back from leading edge of the wing at the fuselage.
You will find a laser engraved C.G. emblem on the inside of the fuselage, located close to the wing tube, which also shows the exact location for Center of Gravity.
